Theatrixx HDMI to Fiber Module – hire & rental

£75.00 per day

The smart way to convert HDMI to fibre for long range video transmission.

Designed as a module of the xVision Reversible Convertor series, it can be inserted in the 8-Bay Frame in either direction, allowing the inputs/outputs to be positioned either at the front or the back of the unit depending on the application. There are no exposed PCBs as all modules are enclosed, and therefore protected against static shock, dust and general wear and tear. Gold-plated, redundant spring pins with magnetic retention deliver DC power to the modules, meaning no messy cabling and external power bricks are needed.

WhitePD hold a comprehensive range of high-end event production equipment in our hire stock. We cover audio, lighting, video, LED walls, rigging set and staging.

Reversible module for Theatrixx 8-bay 3U converter rack
HDMI to fibre for long range transmission
No separate power supply needed
Compact and robust

Video Input:
1 x HDMI 2.0 type A with locking system
Ethernet Port
1 x Gbps Ethernet on Neutrik EtherCON
Video Output:
1 x 10 Gbps Optical Ethernet, SFP-based
Multimode, DUO
SDVoE (NT1000-based)
Typical Latency – < 0.1 ms
Auxiliary Signals – 1 Gbps Ethernet pass-thru

Height: 121.5mm
Width: 41mm
Depth: 225mm
Weight: 710g

Usually supplied with the xVision Reversible 8-Bay Video Converter Frame
Can also be supplied as a standalone item or as part of a larger production package

Long-range transmission of UHD and HD video
Larger conferences and events
To hire the Theatrixx HDMI to Fiber Module please contact us

Description

The smart way to convert HDMI to fibre for long range video transmission.

Designed as a module of the xVision Reversible Convertor series, it can be inserted in the 8-Bay Frame in either direction, allowing the inputs/outputs to be positioned either at the front or the back of the unit depending on the application. There are no exposed PCBs as all modules are enclosed, and therefore protected against static shock, dust and general wear and tear. Gold-plated, redundant spring pins with magnetic retention deliver DC power to the modules, meaning no messy cabling and external power bricks are needed.

WhitePD hold a comprehensive range of high-end event production equipment in our hire stock. We cover audio, lighting, video, LED walls, rigging set and staging.

Additional information

Type

CCS6-602, CCS6-650, CCS6-651, CCS6-S10, CCS6-S15, CCS6-S20, CCS6-S25, CCS6-652S
